2-64 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Theory of Operation
Scanning on Document Glass
The Scanhead travels to read the document. The Scanhead includes the following
components:
•Exposure Lamp that illuminates light onto the document,
• CCD Image Sensor that reads light reflected from the document, and
• Lenses and mirrors comprising the light path for the optical image.
s6500-080
Scanhead
Scanner Home Position Sensor
Carriage Motor
http://www.manuals4you.com

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
