Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 10-5
Wiring
SFP Optional Feeder Plug/Jack Designators
P/J Map Coordinates Remarks
273 5 D-184 Connects Option Feeder (Tray Harness) and Printer
419 5 C-179 Connects Feeder Board and Tray Harness
420 5 D-179 Connects Feeder Board and Tray Comp Harness
421 5 C-180 Connects Feeder Board and Tray Comp Harness
422 5 D-180 Connects Feeder Board and Tray Motor Harness
4201 5 H-181 Connects Turn Clutch and Tray Comp Harness
4202 5 D-185 Connects Paper Path Sensor and Tray Comp Harness
4211 5 F-180 Connects Feed Solenoid and Tray Comp Harness
4212 5 F-185 Connects No Paper Sensor and Tray Comp Harness
4221 5 E-179 Connects Sub Motor (Option Feeder Motor) and Tray
Motor Harness

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
