Xerox Phaser 6500 Service Manual

10-6 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Wiring
SFP Plug/Jack Locator Maps
Map 1 - SFP Print Engine
A
102
103
104
105
106
107
108
109
110
111
112
113
114
115
101
BCDEFGHIJ KL
s6500-425
2811
281
5041
291
141
314
313
312
311
5301
271
272
171
202
http://www.manuals4you.com

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
