Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-157
Error Messages and Codes
IOT Toner Cartridge Life Over
Applicable Error Codes
• 093-930 / 093-931 / 093-932 / 093-933
IOT Print Cartridge Detached
Applicable Error Codes
• 093-970 / 093-971 / 093-972 / 093-973:
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Toner Cartridge (Y) (PL5.1.24)
■ Toner Cartridge (M) (PL5.1.23)
■ Toner Cartridge (C) (PL5.1.22)
■ Toner Cartridge (K) (PL5.1.21)
■ MCU Board (SFP PL8.2.13; MFP
PL8.3.6)
—
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Replace the Toner Cartridge (Y, M, C or
K). (page 8-12)
Does the error still occur when the
power is turned Off and On?
Replace the
MCU Board.
(SFP,
page 8-138;
MFP,
page 8-160)
Complete.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Toner Cartridge (Y) (PL5.1.24)
■ Toner Cartridge (M) (PL5.1.23)
■ Toner Cartridge (C) (PL5.1.22)
■ Toner Cartridge (K) (PL5.1.21)
■ Toner CRUM Harness Assy
(PL5.1.26)
■ MCU Board (SFP PL8.2.13; MFP
PL8.3.6)
■ “Map 1 - SFP Print Engine” on
page 10-6
■ “Map 4 - SFP MCU Board” on
page 10-9
■ “Map 6 - MFP Print Engine” on
page 10-15
■ “Map 9 - MFP MCU Board and HVPS”
on page 10-18
■ “SFP Toner Dispenser” on page 10-32
■ “MFP Toner Dispenser” on page 10-45
