3-92 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Error Messages and Codes
IIT Error
Applicable Error Codes
• 062-311 / 062-321 / 062-322 / 062-360 / 062-371 / 062-393
6 Check the Laser RE Harness Assy for
continuity.
Disconnect P/J40 from the MCU
Board.
Disconnect P/J411 from the Laser
Unit.
Is each cable of J40 <=> J411
continuous?
Go to step 7. Replace the
Laser RE
Harness Assy.
7 Check the Laser Video Harness Assy for
continuity.
Disconnect J41 from the MCU Board.
Disconnect J412 from the Laser Unit.
Is each cable of J41 <=> J412
continuous?
Go to step 8. Replace the
Laser Video
Harness Assy.
8 Check after replacing the Laser Unit.
Replace the Laser Unit. (SFP,
page 8-86; MFP, page 8-92)
Does the error still occur when the
power is turned Off and On?
Replace the
MCU Board.
(SFP,
page 8-138;
MFP,
page 8-160)
Complete.
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IIT Sub Assembly (MFP PL10.1.11)
■ IP Board (ESS) (MFP PL8.1.2)
■ “Map 8 - MFP LVPS, IP Board, and
Drive” on page 10-17
■ “Scanner - IIT Sub-Assembly” on
page 10-49
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Reseat connectors (P/J 1001 and
1002) on the IP Board.
Does the error still occur when turning
the power Off and On?
Go to step 2. Complete.
2 Replace the IIT Sub Assembly.
(page 8-195)
Does the error still occur when turning
the power Off and On?
Replace the IP
Board.
(page 8-144)
Complete.
Troubleshooting Procedure (continued)
Step Actions and Questions Yes No
