Xerox Phaser 6500 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-139
Error Messages and Codes
IOT PHD Life Pre Warning
Applicable Error Code
• 091-402
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ Imaging Unit (PL4.1.21)
■ MCU Board (SFP PL8.2.13; MFP
PL8.3.6)
—
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the life counter value of the
Imaging Unit.
Does the life count value show the
near of the end?
Replace the
Imaging Unit.
(page 8-7)
Go to step 2.
2 Reseat the Imaging Unit.
Does the error still occur when the
power is turned Off and On?
Go to step 3. Complete.
3 Check after replacing the Imaging
Unit.
Replace the Imaging Unit. (page 8-7)
Caution: Be sure to pull all eight
sealing tapes out from a new
Imaging Unit before
installation.
Does the error still occur when the
power is turned Off and On?
Replace the
MCU Board.
(SFP,
page 8-138;
MFP,
page 8-160)
Complete.

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
