Xerox Phaser 6500 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 10-9
Wiring
Map 4 - SFP MCU Board
A
147
148
149
150
151
152
153
154
155
156
157
158
159
160
146
BCDEFGHI J KL
s6500-428
192
422
161
191
182
181
144
11
42
22
21
24
26
15
14
17
101*
31
19
18
29
40 41 10
16 27 20
23
28
: Not Connected

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
