Xerox Phaser 6500 Service Manual

3-94 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Error Messages and Codes
Copy Limit
Applicable Error Code
• 062-790
Troubleshooting Reference Table
Applicable Parts Wiring and Plug/Jack Map References
■ IP Board (ESS) (MFP PL8.1.2) ■ “Map 8 - MFP LVPS, IP Board, and
Drive” on page 10-17
Troubleshooting Procedure
Step Actions and Questions Yes No
1 Check the error.
Does the error message disappear
automatically within 70 seconds, or
disappear after pressing OK?
Go to step 2. Go to step 4.
2 Check the error
Does the error message still occur
when copying, scanning, or faxing the
original?
Go to step 3. Go to step 4.
3 Check the original.
Print System > Information Pages >
Configuration, then copy, scan, or fax
the page.
Does the error still occur when
copying, scanning or faxing the
Configuration page?
Replace the IP
Board. (MFP,
page 8-144)
Complete.
4 Check the error.
Turn the power Off and On.
Does the error message still occur
when copying, scanning, or faxing the
original?
Replace the IP
Board. (MFP,
page 8-144)
Complete.
http://www.manuals4you.com

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
