Xerox Phaser 6500 Service Manual

10-28 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Wiring
SFP Main Drive
SG
MCU Board
PL8.2.13
Feed Drive Assembly
PL7.1.4
Main Drive
Assembly
PL7.1.2
Sub Drive
Assembly
PL7.1.1
1
2
4
5
6
3
8
9
7
P/J22
P/J24
P/J221
9
8
7
6
5
4
3
2
1
I/L +24VDC
SG
I/L +24VDC
SG
SUB MOTO ON
SUB MOT ALARM
SUB MOT CLK
SUB MOT LOW
M
SG
1
2
4
5
6
3
8
9
7
P/J21
P/J211
9
8
7
6
5
4
3
2
1
I/L +24VDC
SG
I/L +24VDC
SG
MAIN MOT ON
MAIN MOT ALARM
MAIN MOT CLK
MAIN MOT LOW
M
s6500-459
Interlock
+24VDC
Interlock
+24VDC
1
2
Main Motor Harness Assembly
PL9.1.7
K Sensor/Registration Clutch
Harness Assembly
PL9.1.9
Sub Motor Harness Assembly
PL9.1.8
I/L +24VDC
K MODE SOL ON (L) +24VDC
Interlock
+24VDC
1
2
3
K MODE SENSED (L) +3.3VDC
SG
3
2
1
PULL UP +3.3VDC
P/J261P/J26
+3.3VDC
Color Mode
Switching
Solenoid
Color Mode
Switching
Sensor
4
5
I/L +24VDC
REGI CL ON (L) +24VDC
2
1
1
2
P/J262
Drive Clutch Assembly
PL3.1.1
Interlock
+24VDC
