Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 10-51
Wiring
MFP Duplex Unit
MCU Board
PL8.2.13
Duplex Harness Assembly
PL11.1.14
P/J604
Duplex Board
PL11.1.16
P/J602
4
3
2
1
Exit Drive
Assembly
PL11.2.2
DUP UP_A
DUP UP_XA
DUP UP_B
DUP UP_XB
I/L +24VDC
DUP CL ON (L) +24VDC
1
2
Duplex Clutch
PL11.2.2
s6500-485
Interlock
+24VDC
+3.3VDC
Interlock
+24VDC
Interlock
+24VDC
+3.3VDC
M
P/J603
5
4
3
2
1
Duplex Drive
Assembly
PL11.2.5
DUP DOWN_A
DUP DOWN_XA
DUP DOWN_XB
DUP DOWN_B
M
P/J27
B1
B2
B3
B4
B5
B6
B7
B8
B9
P/J272
Duplex Relay
Harness Assembly
PL1.2.13
Txd
Rxd
DUP-HOT
+3.3VDC
SG
I/L +24VDC
I/L +24VDC
SG
SG
P/J601
9
10
8
7
6
5
4
3
2
10
9
8
7
6
5
4
3
2
1
2
3
4
5
6
7
8
9
B10
B11
SG
1
1
10
P/J271
9
10
8
7
6
5
4
3
2
1
2
3
4
5
6
7
8
9
110
