Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 2-57
Theory of Operation
s6500-073
Front
Fuser
Duplex Unit
Exit Gear
Cont Clutch Gear
Out Clutch Gear
Idler Gear 24
Gear D1
SN Idler Gear
SN Idler Gear
Idler Gear 18
Exit Motor
Duplex Motor
Exit Roller
[ Duplex Roller Assembly ]
[ Duplex Roller
Assembly ]
Duplex Roller Gear
Duplex Roller Gear
Delay Idler Gear
Delay Idler Gear
Duplex Idler Gear
Idler Gear 16
Gear E1
Duplex Clutch
Clutch Idler Gear
Duplex Output Gear

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
