2-70 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Theory of Operation
Gear Layout
s6500-086
ADF Motor
[ Takeaway Roller ]
[ Exit Roller ]
Gear A
Gear D
Gear E
Gear F
Spring Clutch
[ Feed Roller ]
Feed Roller Assembly
[ Nudger Roller ]
Gear G
Gear I
Gear B
Gear C
Gear H
Gear J
Gear B
Gear C
Gear H
Gear J
