Xerox Phaser 6500 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only xxi
Servicing Electrical Components
Before starting any service procedure, switch the printer power Off and unplug the
power cord from the wall outlet. If you must service the printer with power applied,
be aware of the potential for electrical shock.
Warning
Do not touch any electrical component unless you are instructed to do so by a
service procedure.
Servicing Mechanical Components
When servicing mechanical components within the printer, manually rotate the
Drive Assemblies, Rollers, and Gears.
Warning
Do not try to manually rotate or manually stop the drive assemblies while any
motor is running.
Servicing Fuser Components
Warning
This printer uses heat to fuse the image on the media. When operating, the
Fuser is very hot. Turn the printer power Off and allow the Fuser to cool before
servicing the Fuser or adjacent components.
