Xerox Phaser 6500 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-85
Error Messages and Codes
3 Check the connection between the Fan
and the LVPS.
Is P/J503 on the LVPS connected
correctly?
Go to step 5. Reconnect the
connector P/J
503, then go to
step 4.
4 Does the error still occur when the
power is turned Off and On?
Go to step 5. Complete.
5 Check the connections between the
LVPS and MCU Board.
Are P/J501 and P/J14 connected
correctly?
Go to step 7. Reconnect the
connector(s) P/
J501 and P/
J14 correctly,
then go to step
6.
6 Does the error still occur when the
power is turned Off and On?
Go to step 7. Complete.
7 Check the LVPS Main Harness Assy for
continuity.
Disconnect J501 from the LVPS.
Disconnect J14 from the MCU Board.
Is each wire of J501 <=> J14
continuous?
Go to step 8. Replace the
LVPS Main
Harness Assy.
8 Check the power to the Fan.
Disconnect J503 from the LVPS.
Is the voltage across P503-1 <=>
ground on the LVPS, about +24 VDC
when the interlock switch (Interlock
Harness Assy) is pushed?
Replace the
Fan. (SFP,
page 8-119;
MFP,
page 8-141)
Go to step 9.
9 Replace the LVPS. (SFP, page 8-124;
MFP, page 8-145)
Does the error still occur when the
power is turned Off and On?
Replace the
MCU Board.
(SFP,
page 8-138;
MFP,
page 8-160)
Complete.
Troubleshooting Procedure (continued)
Step Actions and Questions Yes No

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
