Page #231 background imageLoading...
Page #231 background image
Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-103
Error Messages and Codes
20 Check the Tray Motor Harness Assy for
continuity.
Disconnect J422 from the Feeder
Board.
Disconnect J4221 from the Motor
Subassembly.
Is each cable of J422 <=> J4221
continuous?
Go to step 21. Replace the
Tray Motor
Harness Assy.
(PL 12.2.2)
21 Check the power to the Motor.
Disconnect J422 from the Feeder
Board.
Are the voltages across J422-6 <=>
ground on the Feeder Board, about
+24 VDC when the interlock switch
(Interlock Harness Assy) is pushed?
Replace the
Feed Motor Kit.
(page 8-177)
Replace the
Feeder Board.
(page 8-173)
22 Check the connectors of the Feed
Solenoid for connection.
Check the connections between the
Feeder Board and Feed Solenoid.
Are P/J421 and P/J4211 connected
correctly?
Go to step 23. Reconnect the
connector(s) P/
J421 and/or P/
J4211
correctly.
23 Check the HARN TRAY COMP for
continuity.
Disconnect J421 from the Feeder
Board.
Disconnect P4211 from the Feed
Solenoid.
Is each cable of J421 <=> P4211
continuous?
Go to step 24. Replace the
Tray Comp
Harness Assy.
(PL 12.2.20)
24 Check the power to the Feed Solenoid.
Disconnect J421 from the Feeder
Board.
Is the voltage across P421-1 <=>
ground on the Feeder Board, about
+24 VDC when the Interlock Switch
(Interlock Harness Assy) is pushed?
Go to step 25. Replace the
Feeder Board.
(page 8-173)
25 Check the Feed Solenoid for resistance.
Disconnect P/J4211 of the Feed
Solenoid.
Is the resistance across J4211-1 and
J4211-2 approximately 96 ohm?
Replace the
Feeder Board.
(page 8-173)
Replace the
Feed Solenoid
Kit. (page 8-49
26 Check the connectors of the Feed
Clutch (Drive Clutch Assy) for
connection.
Check the connections between the
Feeder Board and Feed Clutch.
Are P/J420 and P/J4201 connected
correctly?
Go to step 27. Reconnect the
connector(s) P/
J420 and/or P/
J4201
correctly.
Troubleshooting Procedure (continued)
Step Actions and Questions Yes No
