Xerox Phaser 6500 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 3-147
Error Messages and Codes
10 Check the power to the Dispenser
Motor Assy.
Disconnect J18 from the MCU Board
and measure the voltage across P18-3
<= > ground on the MCU Board.
Does the voltage measure about +24
VDC when the interlock switch
(Interlock Harness Assy) is pushed?
Replace the
Dispenser Assy.
(SFP,
page 8-98;
MFP,
page 8-104)
Replace the
MCU Board.
(SFP,
page 8-138;
MFP,
page 8-160)
11 Reseat the Imaging Unit.
Does the error still occur when the
power is turned Off and On?
Go to step 12. Complete.
12 Replace the Toner Cartridge (Y, M, C or
K), and check that the lock key is in the
lock position. (page 8-12)
Does the error still occur when the
power is turned Off and On?
Go to step 13. Complete.
13 Replace the Imaging Unit. (page 8-7)
Does the error still occur when the
power is turned Off and On?
Go to step 14. Complete.
14 Reseat the Transfer Belt. connectors?
Does the error still occur when the
power is turned Off and On?
Replace the
Transfer Belt.
(page 8-112)
Complete.
Troubleshooting Procedure (continued)
Step Actions and Questions Yes No
