Xerox Phaser 6500

8-106 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Service Parts Disassembly
20. Release the Dispense Assembly from the boss on the frame, then move the
Dispense Assembly toward the rear to remove it.
s6500-282
Boss
