Theory of Operation
s6500-019
: Laser Beam
: Media Path
Transfer
Belt
[(4) Transfer]
[(7) Cleaning]
Imaging Unit
[(1) Charge]
[(3) Development]
[(4) Transfer]
[(5) Cleaning]
Fuser
[(6) Fusing]
Laser Unit
[(2) Exposure]
