8-164 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Service Parts Disassembly
5. Release 2 hooks that secure the duplex connector to the Duplex Unit.
6. Release 2 hooks that secure the Duplex harness to the duplex connector to
remove the harness.
s6500-348
P/J601
P/J272
