Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 9-17
Parts Lists
4 Chassis FDR R
5 Foot
6—
7—
8 Chassis FDR L
9Bearing
10 Stopper CST 003E73341
11 Solenoid Feed MSI (Manual Feed Solenoid)
12 Spring Lever
13 Lever Feed
14 Spring Feed In
15 Spring Feed Out
16 Gear Feed Out
17 Gear Feed In
18 SFP Harn Assy L Side (J23,J28-P231,J232,J233,J234,
J281)
MFP Harn Assy L Side (J20, J23,J28-J201, P231, J232,
J233,J234, J281)
962K57541
962K87380
19 Gear Assy Feed (With 16,17)
20 SFP Harn Assy Option Dup (J27-P273, P271)
MFP Harness Assy Dup (J27-P273, P271)
962K68772
962K87590
21 —
22 —
23 —
24 —
25 Plate Earth Fdr R
26 —
27 Plate Tie
28 Plate Earth Fdr L (MFP only)
29 —
30 —
31 Plate Earth Fdr (SFP only)
32 Arrester Ene112D-10A
33 Plate Earth CST
97 Kit Clutch Assy Drv (with 1, 2) 675K54231
98 SFP Feeder Assy (with 4,5, 8-15, 18-20, 25, 27, 31-33,
PL3.2.1, PL8.2.7, PL9.1.6)
MFP Feeder Assy (with 4,5, 8-15, 18-20, 25, 27, 28, 31-
33, PL3.2.1, PL8.1.10)
059K72250
059K72260
99 Kit Solenoid Feed (with 11-15, 19) 604K51880
Parts List 3.1 Feeder (1/2) (continued)
Item Description Part Number
To Next Page
