Xerox Phaser 6500 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 9-19
Parts Lists
Parts List 3.2 Feeder (2/2)
Item Description Part Number
1 Chute Assy FDR Regi (With 2-16,20-33, 36)
2 Shaft Assy Feed
3Roll Core MSI
4 Roll Assy Feed 059K60140
5Bearing Earth
6Actuator Regi Out
7 Spring Regi Out
8Actuator Regi Roll
9 Roll Assy Regi
10 Roll Regi Metal
11 Actuator Regi In (Registration Input Actuator) 120E30270
12 Spring Act Regi
13 Sensor Photo 930W00113
14 Actuator SSI 120E27850
15 Spring Act SSI
16 Spring Stp
17 Stopper Act
18 Spring Act Np
19 Actuator No Paper
20 Bearing M Earth
21 Bearing Earth Regi
22 Gear Regi R
23 Gear Regi M
24 Spring Regi R M
25 Plate Earth Regi
26 Chute Up (Upper Feeder Chute)
27 Chute Assy Low (With 34,35) (Lower Chute
Assembly)
28 Bracket Sns
29 Spring Regi L M
30 Bearing M
31 Bearing R
32 Actuator Assy No Paper (With 17-19) 120K92294
33 Plate Weight
34 Chute Assy Low SSI
35 Chute Low CST
36 Film Chute Up

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
