9-22 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Parts Lists
Parts List 4.1 Xerographics
Item Description Part Number
1 ROS Assy (Laser Unit)
2Spring ROS
3Holder CRUM
4Spring PHD
5Lever PHD
6Block Stopper PHD D
7Block Stopper PHD AD
8 LED Assy Erase 122K94041
9 Spring Tracking
10 Spring CF
11 Spring TR4
12 Spring TR3
13 Spring TR2
14 Spring TR1
15 Spring D4
16 Spring D3
17 Spring D2
18 Spring D1
19 PWBA HVPS 105K24390
20 Frame HVPS (SFP only) 801E01504
21 Imaging Unit 676K05360
22 Harn Assy ROS RE (J40-J411)
23 Harn Assy ROS Video (J41-J412)
97 Kit Block PHD Right (with 4, 5, 7 x 2 pcs) 675K54241
98 Kit Block PHD Left (with 4, 5, 6 x 2 pcs) 675K54251
99 Kit ROS Assy (with 1, 2 x 2 pcs) (Laser Unit) 604K64550
http://www.manuals4you.com

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
