Xerox Phaser 6500 Service Manual

9-32 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Parts Lists
SFP Parts List 8.2 Electrical (2/2)
Item Description Part Number
1a
1b
PWBA LVPS 110V
PWBA LVPS 200V
105K24430
105K24440
2 Guide Harness FSR
3 Frame Assy LVPS
4—
5 Harn Assy Interlock (SW-J44) 962K68760
6 Guide Harness AC
7 Sensor HUM 130E93460
8Bracket SW
9a
9b
Harn Assy SW Power (SW-J48, J482, J483) 110V
Harn Assy SW Power (SW-J48, J482, J483) 200V
110K16480
110K16490
10 —
11 —
12 Power Cord
13 PWBA MCU (MCU Board) 960K56363
14 Edging Saddle
15 Bracket MCU R
16 PWBA EEPROM (XPRO) (EEPROM Board) 960K32640
17 Clamp
18 Bracket MCU L
19 Guide Harness MCU
20 —
21 Clamp MST-10V0
22 Cover Inlet
23 Guide Harness Film
24 Plate Earth Drum
25 Plate Earth FSR
26 Arrester ENE112D-10A
