9-36 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual

Parts Lists

MFP Parts List 8.2 Electrical & Frame (2/4)

Item Description Part Number

1 Guide Harness FSR AIO (Fuser Harness Guide)

2 Plate Assy Top (with 3-5)

3Duct Plate

4 Plate Assy Duct

5Seal Plate

6—

7 Duct Fan Assy AIO (with 8,9)

8 Fan 127E85360

9 Duct Fan AIO

10 Shield Harness LVPS

11 Guide Harness LVPS

12a

12b

PWBA LVPS 110V

PWBA LVPS 220V

105K24430

105K24440

13 Chassis LVPS

14 Clamp RLWT-2V0

15 Plate Earth Drum

16 Plate Earth FSR

17 Arrester ENE112D-10A
