Xerox Phaser 6500 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 9-45
Parts Lists
PL10.1 Scanner Assy
Item
Description Part Number
1 Scanner Assy (with 2,3,11)
2 Harn Assy ADF (J1003-JADF1)
3 ADF Assy (with 4-10)
4Cover Top ADF
5 Roll Assy Feed
6 Pad Assy Separator
7 Cover Assy Rear ADF
8 Tray Assy 050K63721
9 Counter Balance L
10 Counter Balance R
11 IIT Assy Sub (IIT Subassembly) 604K66320
12 Core Ferr FFC 121E22020
13 Harness Assy Front USB (J2-J1301)
14 Bracket Assy USB (with 15,16)
15 PWB Assy Front USB
16 Bracket Front USB
95 Kit PWB Assy Front USB (with 13,14) 675K99680
96 —
97 Kit ADF Assy (with 2,3) 675K99690
98 ADF Feed Roll & Separator Roll Kit (with 5-6, Instruction) 604K52222
99 Kit Counter Balance (with 9,10) 604K49540

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
