Xerox Phaser 6500 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 9-47
Parts Lists
Parts List 11.1 Duplex Unit (1/2)
Item Description Part Number
1 Feeder Assy Dup (With 2-16, PL11.2) 059K65450
2Chute Dup In
3 Spring Pinch Dup
4 Roll Pinch Dup
5 Spring Latch Dup
6Latch Dup
7 Follower Latch Dup (SFP only)
8Holder Chute Dup
9Spring Chute Dup
10 Holder Harness Dup
11 Cover Connect Dup (SFP only)
12 Spring Connect Dup (SFP only)
13 Holder Connect Dup (SFP only)
14 Harness Assy Dup (J272-J601) 962K68790
15 Cover PWBA Dup
16 PWBA Dup 960K43081

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
