9-56 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Parts Lists
Parts List 12.3 Optional Feeder (3/5)
Item Description Part Number
1 Spring Earth Opt
2Plate Rear Top
3—
4—
5—
6—
7 Foot (Same as PL3.1.5)
8Plate Earth Ph
9 Chassis FDR R Opt
10 Plate Rear Bottom
11 Plate Front Bottom
12 —
13 Chassis FDR L Opt
14 Plate Earth Front Bottom
15 Bracket Sup Regi
16 Bearing Regi (with PL12.2.6) (Same as PL3.1.97) 675K54231
17 Plate Earth Rear Bottom
18 Plate Earth Rear Top
19 Cover Harness Drawer
20 —
21 Stopper CST (Same as PL3.1.10) 003E73341
22 Bearing
23 Harn Assy Tray (J273-J419) 962K68800
24 Bracket Chassis FDR L (MFP only)
25 Bracket Chassis FDR R (MFP only)
