Xerox Phaser 6500 Service Manual

9-58 Xerox Internal Use Only Phaser 6500/WorkCentre 6505 Service Manual
Parts Lists
Parts List 12.4 Optional Feeder (4/5)
Item Description Part Number
1 Chute Assy Turn (With 2-13, 16, 20-27, 29-33)
2 Shaft Assy Feed
3 Roll Core MSI
4 Roll Assy Feed 059K60140
5Bearing Earth
6Actuator Regi Out
7 Spring Regi Out
8Actuator Regi Roll
9 Roll Assy Regi
10 Roll Regi Metal
11 Actuator Regi In (Option Registration Input Actuator) 120E27820
12 Spring Act Regi
13 Sensor Photo 930W00113
14 —
15 —
16 Spring Stp
17 Stopper Act
18 Spring Act NP
19 Actuator No Paper
20 Bearing M Earth
21 Bearing Earth Regi
22 Gear Regi R
23 Gear Regi M
24 Spring Regi R M
25 Plate Earth Regi
26 Chute Up
27 Chute Low
28 —
29 Spring Regi L M
30 Bearing M
31 Bearing R
32 Actuator Assy No Paper (With 17-19) 120K92294
33 Plate Weight
http://www.manuals4you.com

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
