Xerox Phaser 6500 Service Manual

Phaser 6500/WorkCentre 6505 Service Manual Xerox Internal Use Only 10-3
Wiring
42 4 J-157 Connects MCU Board and Harness Assy PHD XPRO
44 3 D-133 Connects LVPS and Interlock Switch
47 3 G-133 Connects LVPS and Fuser Harness Assy
48 3 G-133 Connects LVPS and Inlet Switch Assy
101 3 D-139 Connects IP Board and IP Board Harness Assy
101 4 I-157 Not Connected (Debug only)
111 3 E-139 Connects IP Board and IP Board Video Harness Assy
141 1 H-107 Connects Erase LED Assy and Main LVPS Harness
144 4 G-151 Connects EEPROM Board and Harness Assy PHD XPRO
161 4 F-153 Connects HVPS and HVPS Harness
171 1 H-107 Connects Fuser and Fuser Harness
181 4 C-152 Connects Y Toner Motor and Toner Motor Harness
182 4 C-151 Connects M Toner Motor and Toner Motor Harness
191 4 C-151 Connects C Toner Motor and Toner Motor Harness
192 4 C-150 Connects K Toner Motor and Toner Motor Harness
201 3 H-141 Connects Humidity Sensor and Humidity Harness
202 3 F-106 Connects Control Panel and Harness Assy A
211 3 I-139 Connects Main Motor and Main Motor Harness
221 3 H-139 Connects Sub Motor and Sub Motor Harness Assy
231 2 C-125 Connects Feed Solenoid and Left Side Harness
232 2 F-125 Connects Registration Sensor and Left Side Harness
233 2 G-125 Connects Manual Feed No Paper Sensor and Left Side
Harness
234 2 F-124 Connects Tray No Paper Sensor and Left Side Harness
261 3 H-140 Connects Color Mode Switching Sensor and K-sensor/
Regi Clutch Harness Assy
262 3 I-140 Connects Drive Clutch and K-sensor/Regi Clutch
Harness Assy
271 1 I-110 Connects Dup Relay Harness and Option Harness
272 1 F-109 Connects Dup Relay Harness Assy and Duplex Module
(Duplex Harness Assy)
273 3 H-142 Connects Option Harness and Option Feeder (Tray
Harness Assy)
281 1 C-108 Connects Transfer Belt (Harness Assy CTD SNR2) and
Left Side Harness
291 1 H-107 Connects Dispenser Assy (Side Door Switch) and
Harness Assy SIDE SW
311 1 H-110 Connects Dispenser Assy (Connector CRUM Y) and
Harness Assy Toner CRUM
SFP Print Engine Plug/Jack Designators (continued)
P/J Map Coordinates
Remarks

Xerox Phaser 6500 Specifications

General

Monthly Duty Cycle	Up to 40, 000 pages
Duplex Printing	Manual
Print Technology	Laser
Maximum Print Resolution	600 x 600 x 4 dpi
First Page Out Time	As fast as 12 seconds
Connectivity	USB 2.0, Ethernet
Paper Capacity	250 sheets + 1 sheet bypass tray
Supported Operating Systems	Windows, Mac OS, Linux
Print Speed	Up to 24 ppm (color) / Up to 24 ppm (black)
