Specifications
Phaser 3610, WorkCentre 3615 Service Manual 8-33
Image Data Transmission Time
Transmission time (T
p
) of image data in G3 mode is as follows:
• Resolution conversion is not performed during transmission, and density is normal.
• Specified value condition: ECM (No data error)
Note: *1: Reference value
Protocol Control Time
When no data error occurs, protocol control time (T
m
, T
n
, T
u
) is as follows:
• V.17, V.29, V.27ter
•V.34
Throughput
The sending time is calculated in the following formula:
• Sending time = Call setup time + Tm + (N x Tp) + {(N-1) x Tn} + Tu (sec) (N: Send quantity,
Tp: Image transmission time)
Chart 14.4Kbps (MMR) 28.8Kbps (MMR)
33.6Kbps
(JBIG)
*1
IIEEJ No.4
Super Fine 56 sec. or less 29 sec. or less 22 sec. or less
Fine 26 sec. or less 13 sec. or less 11 sec. or less
Standard 19 sec. or less 10 sec. or less 7 sec. or less
ITU-T No.1
Super Fine 30 sec. or less 15 sec. or less 12 sec. or less
Fine 15 sec. or less 8 sec. or less 6 sec. or less
Standard 11 sec. or less 6 sec. or less 4 sec. or less
English Sales Text Standard 7 sec. or less 4 sec. or less 2 sec. or less
Japanese Sales Text Standard 9 sec. or less 5 sec. or less 4 sec. or less
IIEEJ No.1 Standard 75 sec. or less 38 sec. or less 20 sec. or less
Mode
Before
messages: Tm
Between
messages: Tn
After
messages: Tu
Total
Standard protocol 16.4 sec. or less 3.2 sec. or less 4.4 sec. or less 24.0 sec. or less
Mode
Before
messages: Tm
Between
messages: Tn
After
messages: Tu
Total
Standard protocol 9.9 sec. or less 1.0 sec. or less 0.9 sec. or less 11.8 sec. or less
