Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-37
077-107 -
<Duplex Regi On Jam>
Cause:
After the Invert Clutch turned ON, the Regi. Sen-
sor did not turn ON within the specified time.
FIP 1. 258
077-108 -
<Exit Off early Jam>
Cause:
After the Exit Sensor turned ON, the Exit Sensor
turned OFF before the specified time.
FIP 1. 257
077-109 -
<Exit Off Jam>
Cause:
After the Regi. Sensor turned OFF, the Exit Sensor
did not turn OFF within the specified time.
FIP 1. 257
077-215
Duplexer Error
Power Off/On
Error 077-215
Power Off/On
<IOT Duplexer Error>
Cause:
Duplex Unit Configuration error is detected.
FIP 1. 285
077-217
Duplexer Error
Power Off/On
Error 077-217
Power Off/On
<Duplex Miss Configuration>
Cause:
Duplex Unit Configuration error is detected.
FIP 1. 285
077-300
Front Cover Open
Close Front Cover
<IOT Cover Front Open>
Cause:
Beep sounds after Front Cover remains open for 3
minutes.
FIP 1. 286
077-304
Rear Door Open
Close Rear Door
<IOT Cover Rear Open>
Cause:
The Rear Cover is open.
FIP 1. 287
077-312
Tray Config Err.
Power Off/On
Error 077-312
Power Off/On
<Tray Configure Error>
Cause:
Tray configuration error was detected.
(including all of the wrong configurations)
FIP 1. 288
091-914
Drum Error
Reseat Drum
Error 091-914
Reseat Drum
<IOT Drum Communication Fail>
Cause:
Communication failure with Drum CRUM was
detected.
FIP 1. 290
Status
Code
(3610)
LCD Message Name/Description of Error FIP

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
