Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual2-36
073-100 -
<IOT Tray 3 Misfeed Jam>
Cause:
After the Tray 3 Feed Clutch turned ON, the Tray 3
Path Sensor did not turn ON within the specified
time.
FIP 1. 265
073-101 -
<IOT Path 3 SNS On Jam>
Cause:
The Tray 3 Path Sensor did not turn ON within the
specified time after the Tray 4 Path Sensor turned
ON.
FIP 1. 277
073-211
Tray3 Error
Power Off/On
Error 073-211
Power Off/On
<Feeder 3 Error>
Cause:
IOT Option Feeder3 Failure.
FIP 1. 280
074-100 -
<IOT Tray 4 Misfeed Jam>
Cause:
After the Tray 4 Feed Clutch turned ON, the Tray 4
Path Sensor did not turn ON within the specified
time.
FIP 1. 265
074-211
Tray4 Error
Power Off/On
Error 074-211
Power Off/On
<Feeder 4 Error>
Cause:
IOT Option Feeder4 Failure.
FIP 1. 280
075-100 -
<MSI Misfeed Jam>
Cause:
After the MSI Feed Solenoid turned ON, the Regi.
Sensor did not turn ON within the specified time.
FIP 1. 281
077-101 -
<VSYNC ON Jam>
Cause:
Detect VSYNC ON Jam.
FIP 1. 282
077-104 -
<Regi. Off Jam>
Cause:
The Regi Sensor does not turn OFF within the
specified time after the Regi Clutch turned On.
FIP 1. 283
077-106 -
<Exit On Jam>
Cause:
The Exit Sensor does not turn ON within the speci-
fied time after the Regi Clutch turned On.
FIP 1. 257
Status
Code
(3610)
LCD Message Name/Description of Error FIP

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
