Xerox WorkCentre 3615 Service Manual

Troubleshooting
Phaser 3610, WorkCentre 3615 Service Manual 2-35
061-370
Laser Error
Power Off/On
Error 061-370
Power Off/On
<IOT ROS Failure>
Cause:
The operation error of ROS (rotational error etc.) is
detected.
FIP 1. 269
071-100 -
<IOT Tray1 Misfeed Jam>
Cause:
After the Tray 1 Feed Clutch turned ON, the Regi.
Sensor did not turn ON within the specified time.
FIP 1. 273
071-920
Insert Output
to NNN
<Waiting to Print Side 2 Load Printed Pages into
the NNN>
Cause:
Waiting for side 2 to be set for manual duplex
print (Tray).
FIP 1. 274
071-921
Press Ok Button
to continue
<Manual Duplex Print>
Cause:
Waiting for Set key to be pressed after setting side
2 for manual duplex print (Tray).
FIP 1. 275
072-100 -
<IOT Tray2 Misfeed Jam>
Cause:
After the Tray 2 Feed Clutch turned ON, the Tray 2
Path Sensor did not turn ON within the specified
time.
FIP 1. 265
072-101 -
<IOT Path 2 SNS On Jam>
Cause:
The Tray 2 Path Sensor did not turn ON within the
specified time after the Tray 3 Path Sensor turned
ON.
FIP 1. 277
072-102 -
<IOT Option Regi On Jam>
Cause:
After the Tray 2 Path Sensor turned ON, the Regi.
Sensor did not turn ON within the specified time.
FIP 1. 278
072-211
Tray2 Error
Power Off/On
Error 072-211
Power Off/On
<Feeder 2 Error>
Cause:
IOT Option Feeder2 Failure.
FIP 1. 279
Status
Code
(3610)
LCD Message Name/Description of Error FIP

Xerox WorkCentre 3615 Specifications

General

Print Technology	Laser
Print Resolution	Up to 1200 x 1200 dpi
Fax	Yes
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Processor	533 MHz
Memory (Standard)	256 MB
Paper Output	250 sheets
Fax Speed	33.6 kbps
Print Speed	47 ppm
Scan Resolution	600 x 600 dpi
Automatic Document Feeder	50 sheets
Connectivity	Ethernet
First Page Out Time (Copy)	8.5 seconds
Paper Capacity	250 sheets
Network Connectivity	Ethernet
Operating System Compatibility	Windows, Mac, Linux
