ECG signal processing and display
The number of ECG leads available depends on
the cable and lead wire sets used:
ECG connection cable Lead wire
set
Display channels Leads available
MULTIMED 5, 6,
MULTIMED PLUS OR
3-lead ECG 1 or ECG 2 or ECG 3 I, II, III
MULTIMED 5, 6,
MULTIMED PLUS OR
5-lead ECG 1, ECG 2, ECG 3 I, II, III, aVR, aVL, aVF, V
MULTIMED 6,
MULTIMED PLUS OR
6-lead ECG 1, ECG 2, ECG 3 I, II, III, aVR, aVL, aVF, V, V+
