Configuration
352
Instructions for use Zeus Infinity Empowered SW 2.n
The following table (E) shows the default values:
C All: All waveforms are displayed. The various
waveform colors are assigned in a legend.
D Active: Only the enabled waveforms are dis-
played. The various waveform colors are as-
signed in a legend.
Total consumption
The page More settings > Total consumpt.
opens.
A Total consumption: The consumption of O
2,
Air, N2O and the volatile anesthetic agent since
startup of Zeus IE are displayed
B Consumption since reset: The consumption
of O2, Air, N2O and the volatile anesthetic
agents since the last reset are displayed
C Reset: Sets all values for O
2, Air, N2O and the
volatile anesthetic agents to 0. The time of last
reset is displayed in (D).
Weight
kg
VT
mL
RR
1/min
21535
15 110 26
65 450 13
100 700 10
456
Basic settings
A
B
C
D
