• Upon assertion of the event in (EVTI) pin, the first data trace message will be a synchronization
message if the EIC bits of the DC1 register have enabled this feature
• Upon data trace write/read after the previous DTM message was lost due to an attempted access to
a secure memory location
• Upon data trace write/read after the previous DTM message was lost due to a collision entering the
FIFO between the DTM message and any of the following: watchpoint message, ownership trace
message, or branch trace message
Data trace synchronization messages provide the full address (without leading zeros) and insure that
development tools fully synchronize with data trace regularly. Synchronization messages provide a
reference address for subsequent data messages, in which only the unique portion of the data trace address
is transmitted. The format for data trace write/read with sync. messages is as follows:
Figure 25-44. Data Write/Read with Sync. Message Format
Exception conditions that result in data trace synchronization are summarized in Table 25-36.
Table 25-36. Data Trace Exception Summary
Exception Condition Exception Handling
System Reset Negation At the negation of JTAG reset (JCOMP), queue pointers, counters, state machines,
and registers within the NZ6C3 module are reset. If data trace is enabled, the first
data trace message is a data write/read with sync. message.
Data Trace Enabled The first data trace message (after data trace has been enabled) is a
synchronization message.
Exit from Low Power/Debug Upon exit from a low power mode or debug mode the next data trace message will
be converted to a data write/read with sync. message.
Queue Overrun An error message occurs when a new message cannot be queued due to the
message queue being full. The FIFO will discard messages until it has completely
emptied the queue. After it is emptied, an error message will be queued. The error
encoding will indicate which types of messages attempted to be queued while the
FIFO was being emptied. The next DTM message in the queue will be a data
write/read with sync. message.
Periodic Data Trace Sync. A forced synchronization occurs periodically after 255 data trace messages have
been queued. A data write/read with sync. message is queued. The periodic data
trace message counter then resets.
Event In If the Nexus module is enabled, a EVTI assertion initiates a data trace write/read
with sync. message upon the next data write/read (if data trace is enabled and the
EIC bits of the DC1 register have enabled this feature).
Attempted Access to Secure
Memory
For devices which implement security, any attempted read or write to secure
memory locations will temporarily disable data trace & cause the corresponding
DTM to be lost. A subsequent read/write will queue a data trace read/write with
sync. message.
DATA
msb lsb
234
F-ADDR DSZ SRC
5
4 bits
1
TCODE (001101 or 001110)
3 bits1-32 bits1-64 bits 6 bits
Max length = 109 bits; Min length = 15 bits
