GPIO pin data output register 141 SIU_GPDO141 8-bits Base + 0x068D
GPIO pin data output register 142 SIU_GPDO142 8-bits Base + 0x068E
GPIO pin data output register 143 SIU_GPDO143 8-bits Base + 0x068F
GPIO pin data output register 144 SIU_GPDO144 8-bits Base + 0x0690
GPIO pin data output register 145 SIU_GPDO145 8-bits Base + 0x0691
GPIO pin data output register 146 SIU_GPDO146 8-bits Base + 0x0692
GPIO pin data output register 147 SIU_GPDO147 8-bits Base + 0x0693
GPIO pin data output register 148 SIU_GPDO148 8-bits Base + 0x0694
GPIO pin data output register 149 SIU_GPDO149 8-bits Base + 0x0695
GPIO pin data output register 150 SIU_GPDO150 8-bits Base + 0x0696
GPIO pin data output register 151 SIU_GPDO151 8-bits Base + 0x0697
GPIO pin data output register 152 SIU_GPDO152 8-bits Base + 0x0698
GPIO pin data output register 153 SIU_GPDO153 8-bits Base + 0x0699
GPIO pin data output register 154 SIU_GPDO154 8-bits Base + 0x069A
GPIO pin data output register 155 SIU_GPDO155 8-bits Base + 0x069B
GPIO pin data output register 156 SIU_GPDO156 8-bits Base + 0x069C
GPIO pin data output register 157 SIU_GPDO157 8-bits Base + 0x069D
GPIO pin data output register 158 SIU_GPDO158 8-bits Base + 0x069E
GPIO pin data output register 159 SIU_GPDO159 8-bits Base + 0x069F
GPIO pin data output register 160 SIU_GPDO160 8-bits Base + 0x06A0
GPIO pin data output register 161 SIU_GPDO161 8-bits Base + 0x06A1
GPIO pin data output register 162 SIU_GPDO162 8-bits Base + 0x06A2
GPIO pin data output register 163 SIU_GPDO163 8-bits Base + 0x06A3
GPIO pin data output register 164 SIU_GPDO164 8-bits Base + 0x06A4
GPIO pin data output register 165 SIU_GPDO165 8-bits Base + 0x06A5
GPIO pin data output register 166 SIU_GPDO166 8-bits Base + 0x06A6
GPIO pin data output register 167 SIU_GPDO167 8-bits Base + 0x06A7
GPIO pin data output register 168 SIU_GPDO168 8-bits Base + 0x06A8
GPIO pin data output register 169 SIU_GPDO169 8-bits Base + 0x06A9
GPIO pin data output register 170 SIU_GPDO170 8-bits Base + 0x06AA
GPIO pin data output register 171 SIU_GPDO171 8-bits Base + 0x06AB
GPIO pin data output register 172 SIU_GPDO172 8-bits Base + 0x06AC
Table A-2. MPC5554 / MPC5553 Detailed Register Map (Continued)
Register Description Register Name
Used
Size
Address Reference
To Next Page
