MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
A-40 Freescale Semiconductor
Channel priority register 41 EDMA_CPR41 8-bit Base + 0x0129
Channel priority register 42 EDMA_CPR42 8-bit Base + 0x012A
Channel priority register 43 EDMA_CPR43 8-bit Base + 0x012B
Channel priority register 44 EDMA_CPR44 8-bit Base + 0x012C
Channel priority register 45 EDMA_CPR45 8-bit Base + 0x012D
Channel priority register 46 EDMA_CPR46 8-bit Base + 0x012E
Channel priority register 47 EDMA_CPR47 8-bit Base + 0x012F
Channel priority register 48 EDMA_CPR48 8-bit Base + 0x0130
Channel priority register 49 EDMA_CPR49 8-bit Base + 0x0131
Channel priority register 50 EDMA_CPR50 8-bit Base + 0x0132
Channel priority register 51 EDMA_CPR51 8-bit Base + 0x0133
Channel priority register 52 EDMA_CPR52 8-bit Base + 0x0134
Channel priority register 53 EDMA_CPR53 8-bit Base + 0x0135
Channel priority register 54 EDMA_CPR54 8-bit Base + 0x0136
Channel priority register 55 EDMA_CPR55 8-bit Base + 0x0137
Channel priority register 56 EDMA_CPR56 8-bit Base + 0x0138
Channel priority register 57 EDMA_CPR57 8-bit Base + 0x0139
Channel priority register 58 EDMA_CPR58 8-bit Base + 0x013A
Channel priority register 59 EDMA_CPR59 8-bit Base + 0x013B
Channel priority register 60 EDMA_CPR60 8-bit Base + 0x013C
Channel priority register 61 EDMA_CPR61 8-bit Base + 0x013D
Channel priority register 62 EDMA_CPR62 8-bit Base + 0x013E
Channel priority register 63 EDMA_CPR63 8-bit Base + 0x013F
Reserved — — Base + (0x0140-0x0FFF)
Transfer control descriptor register 0 TCD0 256-bit Base + 0x1000
Transfer control descriptor register 1 TCD1 256-bit Base + 0x1020
Transfer control descriptor register 2 TCD2 256-bit Base + 0x1040
Transfer control descriptor register 3 TCD3 256-bit Base + 0x1060
Transfer control descriptor register 4 TCD4 256-bit Base + 0x1080
Transfer control descriptor register 5 TCD5 256-bit Base + 0x10A0
Transfer control descriptor register 6 TCD6 256-bit Base + 0x10C0
Transfer control descriptor register 7 TCD7 256-bit Base + 0x10E0
Table A-2. MPC5554 / MPC5553 Detailed Register Map (Continued)
Register Description Register Name
Used
Size
Address Reference
