System Interface Unit (SIU)
MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
6-46 Freescale Semiconductor
Figure 6-41. OE_GPIO[68] Pad Configuration Register (SIU_PCR68)
6.3.1.12.29 Pad Configuration Register 69 (SIU_PCR69)
The SIU_PCR69 register controls the pin function, direction, and static electrical attributes of the
TS_GPIO[69] pin. Because the MPC5553 calibration bus interface (CBI) and external bus interface (EBI)
share the same physical bus, the MPC5553 uses the TS signal for the CBI as well as the EBI.
Address: Base + 0x00C8 Access: Read / write[5:11, 14:15]
0123456789101112131415
R 00000
PA OBE
1
1
When configured as OE , the OBE bit has no effect. When configured as GPO, set the OBE bit to 1.
IBE
2
2
When configured as OE or GPO, set the IBE bit to 1 to reflect the pin state in the corresponding GPDI register. Clearing the IBE
bit to 0 reduces power consumption. When configured as GPI, set the IBE bit to 1.
DSC ODE
3
3
When configured as OE, clear the ODE bit to 0.
HYS
4
4
If the external master operation is enabled, set the HYS bit to 1.
00
WPE
5
5
Refer to the EBI section for weak pullup settings when configured as OE.
WPS
5
W
RESET: 000000001100001 1
Table 6-36. PCR68 PA Field Definition
PA Field Pin Function
0b0 GPIO[68]
0b1 OE
Address: Base + 0x00CA Access: Read / write[5:11, 14:15]
0123456789101112131415
R 00000
PA OBE
1
1
When configured as TS, the OBE bit has no effect. When configured as GPO, set the OBE bit to 1.
IBE
2
2
When configured as TS, or GPO, set the IBE bit to 1 to reflect the pin state in the corresponding GPDI register. Clearing the IBE
bit to 0 reduces power consumption. When configured as GPI, set the IBE bit to 1.
DSC ODE
3
3
When configured as TS, clear the ODE bit to 0.
HYS
4
4
If external master operation is enabled, clear the HYS bit to 0.
00
WPE
5
5
Refer to the EBI section for weak pullup settings when configured as TS.
TS_GPIO[69] Pad Configuration Register (SIU_PCR69)
WPS
5
W
RESET: 000000001100001 1
Table 6-37. PCR69 PA Field Definition
PA Field Pin Function
0b0 GPIO[69]
0b1 TS
