MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
10-20 Freescale Semiconductor
eQADC
0x0640 100 EQADC_FISRx[TORF]
EQADC_FISRx[RFOF]
EQADC_FISRx[CFUF]
EQADC_FISRx[TORF]
EQADC_FISRx[RFOF]
EQADC_FISRx[CFUF]
eQADC combined overrun interrupt request s from
all of the FIFOs:
Trigger Overrun, Receive FIFO Overflow, and
command FIFO Underflow
0x0650 101 EQADC_FISR0[NCF] EQADC_FISR0[NCF] eQADC command FIFO 0 Non-Coherency Flag
0x0660 102 EQADC_FISR0[PF] EQADC_FISR0[PF] eQADC command FIFO 0 Pause Flag
0x0670 103 EQADC_FISR0[EOQF] EQADC_FISR0[EOQF] eQADC command FIFO 0 command queue End of
Queue Flag
0x0680 104 EQADC_FISR0[CFFF] EQADC_FISR0[CFFF] eQADC Command FIFO 0 Fill Flag
0x0690 105 EQADC_FISR0[RFDF] EQADC_FISR0[RFDF] eQADC Receive FIFO 0 Drain Flag
0x06A0 106 EQADC_FISR1[NCF] EQADC_FISR1[NCF] eQADC command FIFO 1 Non-Coherency Flag
0x06B0 107 EQADC_FISR1[PF] EQADC_FISR1[PF] eQADC command FIFO 1 Pause Flag
0x06C0 108 EQADC_FISR1[EOQF] EQADC_FISR1[EOQF] eQADC command FIFO 1 command queue End of
Queue Flag
0x06D0 109 EQADC_FISR1[CFFF] EQADC_FISR1[CFFF] eQADC Command FIFO 1 Fill Flag
0x06E0 110 EQADC_FISR1[RFDF] EQADC_FISR1[RFDF] eQADC Receive FIFO 1 Drain Flag
0x06F0 111 EQADC_FISR2[NCF] EQADC_FISR2[NCF] eQADC command FIFO 2 Non-Coherency Flag
0x0700 112 EQADC_FISR2[PF] EQADC_FISR2[PF] eQADC command FIFO 2 Pause Flag
0x0710 113 EQADC_FISR2[EOQF] EQADC_FISR2[EOQF] eQADC command FIFO 2 command queue End of
Queue Flag
0x0720 114 EQADC_FISR2[CFFF] EQADC_FISR2[CFFF] eQADC Command FIFO 2 Fill Flag
0x0730 115 EQADC_FISR2[RFDF] EQADC_FISR2[RFDF] eQADC Receive FIFO 2 Drain Flag
0x0740 116 EQADC_FISR3[NCF] EQADC_FISR3[NCF] eQADC command FIFO 3 Non-Coherency Flag
0x0750 117 EQADC_FISR3[PF] EQADC_FISR3[PF] eQADC command FIFO 3 Pause Flag
0x0760 118 EQADC_FISR3[EOQF] EQADC_FISR3[EOQF] eQADC command FIFO 3 command queue End of
Queue Flag
0x0770 119 EQADC_FISR3[CFFF] EQADC_FISR3[CFFF] eQADC Command FIFO 3 Fill Flag
0x0780 120 EQADC_FISR3[RFDF] EQADC_FISR3[RFDF] eQADC Receive FIFO 3 Drain Flag
0x0790 121 EQADC_FISR4[NCF] EQADC_FISR4[NCF] eQADC command FIFO 4 Non-Coherency Flag
0x07A0 122 EQADC_FISR4[PF] EQADC_FISR4[PF] eQADC command FIFO 4 Pause Flag
0x07B0 123 EQADC_FISR4[EOQF] EQADC_FISR4[EOQF] eQADC command FIFO 4 command queue End of
Queue Flag
0x07C0 124 EQADC_FISR4[CFFF] EQADC_FISR4[CFFF] eQADC Command FIFO 4 Fill Flag
Table 10-9. INTC: Interrupt Request Sources (Continued)
Hardware
Vector
Mode
Offset
Vector
Source
1
MPC5553
Source
1
MPC5554
Description
