0x022C RMON_T_P65TO127 RMON Tx 65 to 127 byte packets
0x0230 RMON_T_P128TO255 RMON Tx 128 to 255 byte packets
0x0234 RMON_T_P256TO511 RMON Tx 256 to 511 byte packets
0x0238 RMON_T_P512TO1023 RMON Tx 512 to 1023 byte packets
0x023C RMON_T_P1024TO2047 RMON Tx 1024 to 2047 byte packets
0x0240 RMON_T_P_GTE2048 RMON Tx packets w > 2048 bytes
0x0244 RMON_T_OCTETS RMON Tx Octets
0x0248 IEEE_T_DROP Count of frames not counted correctly
0x024C IEEE_T_FRAME_OK Frames Transmitted OK
0x0250 IEEE_T_1COL Frames Transmitted with Single Collision
0x0254 IEEE_T_MCOL Frames Transmitted with Multiple Collisions
0x0258 IEEE_T_DEF Frames Transmitted after Deferral Delay
0x025C IEEE_T_LCOL Frames Transmitted with Late Collision
0x0260 IEEE_T_EXCOL Frames Transmitted with Excessive Collisions
0x0264 IEEE_T_MACERR Frames Transmitted with Tx FIFO Underrun
0x0268 IEEE_T_CSERR Frames Transmitted with Carrier Sense Error
0x026C IEEE_T_SQE Frames Transmitted with SQE Error
0x0270 IEEE_T_FDXFC Flow Control Pause frames transmitted
0x0274 IEEE_T_OCTETS_OK Octet count for Frames Transmitted w/o Error
0x0280 RMON_R_DROP Count of frames not counted correctly
0x0284 RMON_R_PACKETS RMON Rx packet count
0x0288 RMON_R_BC_PKT RMON Rx Broadcast Packets
0x028C RMON_R_MC_PKT RMON Rx Multicast Packets
0x0290 RMON_R_CRC_ALIGN RMON Rx Packets w CRC/Align error
0x0294 RMON_R_UNDERSIZE RMON Rx Packets < 64 bytes, good crc
0x0298 RMON_R_OVERSIZE RMON Rx Packets > MAX_FL bytes, good crc
0x029C RMON_R_FRAG RMON Rx Packets < 64 bytes, bad crc
0x02A0 RMON_R_JAB RMON Rx Packets > MAX_FL bytes, bad crc
0x02A4 — Reserved
0x02A8 RMON_R_P64 RMON Rx 64 byte packets
0x02AC RMON_R_P65TO127 RMON Rx 65 to 127 byte packets
Table 14-3. MIB Counters Memory Map (Continued)
Address
Offset
1
(Base +)
Mnemonic Description
