CNTXC_
PCSD[3]_
GPIO[87]
FlexCAN C Transmit
DSPI D Peripheral Chip Select
General Purpose I/O
P
A
G
O
O
I/O
V
DDEH6
MH – / Up – / Up W24 V23
CNRXC_
PCSD[4]_
GPIO[88]
FlexCAN C Receive
DSPI D Peripheral Chip Select
General Purpose I/O
P
A
G
I
O
I/O
V
DDEH6
MH – / Up – / Up Y26 W24
Table 2-2. MPC5554 Signal Properties (Continued)
Signal Names
1
Signal Functions
2
P/
A/
G
I/O
Type
Voltage
3
Pad
Type
4
Status Pin Labels / Package
During
Reset
5
After
Reset
6
496
7
416
