MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
20-20 Freescale Semiconductor
Table 20-6. DSPIx_SR Field Descriptions
Bits Name Description
0 TCF Transfer complete flag. Indicates that all bits in a frame have been shifted out. The TCF bit is
set after the last incoming databit is sampled, but before the tASC delay starts. Refer to
Section 20.4.7.1, “Classic SPI Transfer Format (CPHA = 0)” for details. The TCF bit is cleared
by writing 1 to it.
0 Transfer not complete
1 Transfer complete
1 TXRXS TX and RX status. Reflects the status of the DSPI. See Section 20.4.2, “Start and Stop of
DSPI Transfers” for information on what causes this bit to be negated or asserted. TXRXS is
cleared by writing 1 to it.
0 TX and RX operations are disabled (DSPI is in STOPPED state)
1 TX and RX operations are enabled (DSPI is in RUNNING state)
2 — Reserved.
3 EOQF End of queue flag. Indicates that transmission in progress is the last entry in a queue. The
EOQF bit is set when the TX FIFO entry has the EOQ bit set in the command halfword and
after the last incoming databit is sampled, but before the tASC delay starts. Refer to
Section 20.4.7.1, “Classic SPI Transfer Format (CPHA = 0)” for details.
The EOQF bit is cleared by writing 1 to it. When the EOQF bit is set, the TXRXS bit is
automatically cleared.
0 EOQ is not set in the executing command
1 EOQ bit is set in the executing SPI command
Note: EOQF does not function in slave mode.
4 TFUF Transmit FIFO underflow flag. Indicates that an underflow condition in the TX FIFO has
occurred. The transmit underflow condition is detected only for DSPI modules operating in
slave mode and SPI configuration. The TFUF bit is set when the TX FIFO of a DSPI operating
in SPI slave mode is empty, and a transfer is initiated by an external SPI master. The TFUF bit
is cleared by writing 1 to it.
0 TX FIFO underflow has not occurred
1 TX FIFO underflow has occurred
5 — Reserved.
6 TFFF Transmit FIFO fill flag: indicates that the TX FIFO can be filled. Provides a method for the DSPI
to request more entries to be added to the TX FIFO. The TFFF bit is set while the TX FIFO is
not full. The TFFF bit can be cleared by writing 1 to it or by an acknowledgement from the
eDMA controller when the TX FIFO is full.
0 TX FIFO is full
1 TX FIFO is not full
7–11 — Reserved.
12 RFOF Receive FIFO overflow flag. Indicates that an overflow condition in the RX FIFO has occurred.
The bit is set when the RX FIFO and shift register are full and a transfer is initiated. The bit is
cleared by writing 1 to it.
0 RX FIFO overflow has not occurred
1 RX FIFO overflow has occurred
13 — Reserved.
