MPC5553/MPC5554 Microcontroller Reference Manual, Rev. 5
Freescale Semiconductor 20-21
20.3.2.5 DSPI DMA/Interrupt Request Select and Enable Register (DSPIx_RSER)
The DSPIx_RSER serves two purposes. It enables flag bits in the DSPIx_SR to generate DMA requests or
interrupt requests. The DSPIx_RSER also selects the type of request to be generated. See the individual
bit descriptions for information on the types of requests the bits support. The user must not write to the
DSPIx_RSER while the DSPI is running.
14 RFDF Receive FIFO drain flag: indicates that the RX FIFO can be drained. Provides a method for the
DSPI to request that entries be removed from the RX FIFO. The bit is set while the RX FIFO
is not empty. The RFDF bit can be cleared by writing 1 to it or by an acknowledgement from
the eDMA controller when the RX FIFO is empty.
0 RX FIFO is empty
1 RX FIFO is not empty
Note: In the interrupt service routine, RFDF must be cleared only after the DSPIx_POPR
register is read.
15 — Reserved.
16–19 TXCTR
[0:3]
TX FIFO counter. Indicates the number of valid entries in the TX FIFO. The TXCTR is
incremented every time the DSPI _PUSHR is written. The TXCTR is decremented every time
an SPI command is executed and the SPI data is transferred to the shift register.
20–23 TXNXTPTR
[0:3]
Transmit next pointer. Indicates which TX FIFO Entry will be transmitted during the next
transfer. The TXNXTPTR field is updated every time SPI data is transferred from the TX FIFO
to the shift register. See Section 20.4.3.4, “Transmit First In First Out (TX FIFO) Buffering
Mechanism” for more details.
24–27 RXCTR
[0:3]
RX FIFO counter. Indicates the number of entries in the RX FIFO. The RXCTR is decremented
every time the DSPI _POPR is read. The RXCTR is incremented after the last incoming databit
is sampled, but before the tASC delay starts. Refer to Section 20.4.7.1, “Classic SPI Transfer
Format (CPHA = 0)” for details.
28–31 POPNXTPTR
[0:3]
Pop next pointer. Contains a pointer to the RX FIFO entry that will be returned when the
DSPIx_POPR is read. The POPNXTPTR is updated when the DSPIx_POPR is read. See
Section 20.4.3.5, “Receive First In First Out (RX FIFO) Buffering Mechanism” for more details.
Table 20-6. DSPIx_SR Field Descriptions (Continued)
Bits Name Description
