4 Input/Output Functions
Input/Output
Min 0 s
Max +100 ns
Initial S/W Revision Prior to A.02.00
Q Probe
Accesses the probe setup parameters for the Q channel. See"I/Q Probe Setup" on page 172.
Key Path
Input/Output, I/Q, Q Setup
State Saved No
Readback Text [<Q port probe id>]
This is reporting the type of probe sensed on the Q port. There is no parameter for overriding what is
sensed.
Initial S/W Revision Prior to A.02.00
Attenuation
The attenuation is part of the calibration data stored with the probe type and is initially the value that was
returned by the last calibration. You can modify this value and any changes will be stored with the
calibration data and will survive power cycles and presets. When a probe calibration is performed the
attenuation value will be overwritten by the calibration.
Key Path
Input/Output, I/Q, I Setup | Q Setup, I Probe | Q Probe
Remote Command
[:SENSe]:CORRection:IQ:I|Q:ATTenuation:RATio <real>
[:SENSe]:CORRection:IQ:I|Q:ATTenuation:RATio?
Example Set the attenuation for the current I probe to 100.00:1.
CORR:IQ:I:ATT:RAT 100
Notes Each probe type has its own attenuation setting. As probes are changed the attenuation value will
reflect the new probe's setting. Changing the attenuation affects only the current probe type's setting
and leaves all others unchanged.
When the IQ Path is I+jQ, the Q probe attenuation setting must match the I Probe attenuation setting
within 1 dB. If this is not the case, an error condition message is generated, 159;Settings Alert;I/Q
mismatch:Attenuation.
Preset Each probe type has its own default. The default for the "Unknown" probe type is 1:1.
State Saved Saved with probe calibration data. It survives a power cycle and is not affected by a Preset or
Restore.
Range 0.001 to 10000
Min 0.001
Max 10000
Initial S/W Revision Prior to A.02.00
EMI Receiver Mode Reference 169
