8 Frequency Scan Measurement
Trace/ Detector
n* 4 bytes measurement results of trace 2 if trace 2 update is true; else return 0
n* 4 bytes measurement results of trace 3 if trace 3 update is true; else return 0
Backwards
Compatibility SCPI
:TRACe[:DATA]?
Backwards Compatibility
SCPI Notes
This command is included for ESU compatibility. The SCPI is Meas Local and Context Sensitive.
Initial S/W Revision A.07.00
Remote Command
TRACe:FEED:CONTrol ALWays|NEVer
TRACe:FEED:CONTrol?
Example TRAC:FEED:CONT ALW Allow block data transmission
Notes This ESU command switches block data transmission during a scan on and off. The availability of
data is reported in the bit 9 of STATus:OPERation-Register.The block size depends on scan time.
Preset NEVer
Backwards Compatibility SCPI commands
"Trace Display (Remote Command Only)" on page 588
"Detector Type (Remote Command Only)" on page 588
Trace Display (Remote Command Only)
This SCPI sets the trace’s Update state.
Remote Command
DISPlay[:WINDow]:TRACe[1]|2|3[:STATe] ON|OFF|1|0
DISPlay[:WINDow]:TRACe[1]|2|3[:STATe]?
Example DISP:TRAC OFF
DISP:TRAC?
Notes This command is included for ESU compatibility. The suffix [1]|2 and [1]|2|3 are irrelevant to the
measurement, they are added solely for remote language compatibility. This SCPI alias to :TRACe[1]
|2|3:FSCan:UPDate ON|OFF|1|0.
Backwards
Compatibility SCPI
DISPlay:WINDow[1]|2:TRACe[1]|2|3[:STATe]
Initial S/W Revision A.07.00
Detector Type (Remote Command Only)
Select the detector used for the selected trace.
Remote Command
[:SENSe]:DETector[1]|2|3[:FUNCtion] APEak | NEGative | POSitive |
SAMPle | RMS | AVERage | QPEak | CAVerage | CRMS
588 EMI Receiver Mode Reference
