9 Strip Chart Measurement
AMPTD Y Scale
:POW:GAIN:BAND LOW
Readback Low Band
Initial S/W Revision Prior to A.02.00
Full Range
Sets the internal preamp to use its full range. The low band (0–3.6GHz or 0–3GHz, depending on the
model) is supplied by the low band preamp and the frequencies above low band are supplied by the high
band preamp.
The frequency range of the installed (optional) preamp is displayed in square brackets on the Full Range
key label. If the high band option is not installed the Full Range key does not appear.
Key Path
AMPTD Y Scale, Internal Preamp
Example :POW:GAIN ON
:POW:GAIN:BAND FULL
Readback Full Range
Initial S/W Revision Prior to A.02.00
EMI Receiver Mode Reference 621
