5 Mode Functions
Mode
iDEN/WiDEN/MOTOTalk
Selects the iDEN/WiDEN/MOTOTalk mode for general purpose measurements of iDEN and iDEN-related
signals. There are several measurements available in this mode.
If you are using the Help feature, this mode must be currently active to access its detailed information. If it
is not active, exit the Help feature (Esc key), select the mode, and re-access Help.
Key Path
Mode
Example INST:SEL IDEN
INST:NSEL 103
Initial S/W Revision A.02.00
IQ Analyzer (Basic)
The IQ Analyzer Mode makes general purpose frequency domain and time domain measurements. These
measurements often use alternate hardware signal paths when compared with a similar measurement in
the Signal Analysis Mode using the Swept SA measurement. These frequency domain and time domain
measurements can be used to output I/Q data results when measuring complex modulated digital signals.
If you are using the Help feature, this mode must be currently active to access its detailed information. If it
is not active, exit the Help feature (Esc key), select the mode, and re-access Help.
Key Path
Mode
Example INST:SEL BASIC
INST:NSEL 8
Initial S/W Revision Prior to A.02.00
ISDB-T
Selects the ISDB-T mode for measurements of digital video signals using this format. There are several
power and demod measurements available in this mode.
If you are using the Help feature, this mode must be currently active to access its detailed information. If it
is not active, exit the Help feature (Esc key), select the mode, and re-access Help.
Key Path
Mode
Example INST:SEL ISDBT
INST:NSEL 239
Initial S/W Revision A.03.00
LTE
Selects theLTE mode for general purpose measurements of signals following the LTE FDD standard. There
are several measurements available in this mode.
238 EMI Receiver Mode Reference
