10 Monitor Spectrum Measurement
AMPTD Y Scale
Example UNIT:POW DBUAM
Dependencies Grayed out if no Amplitude Correction with an Antenna Unit is on.
Readback dBµA/m
Initial S/W Revision A.02.00
dBµA
Sets the amplitude unit for the selected amplitude scale (log/lin) to dBµA. This is an antenna unit, and this
key is grayed out unless a Correction with this Antenna Unit selected is ON. If this is the case, all of the
other Antenna Units are grayed out.
Key Path
AMPTD Y Scale, Y Axis Unit, Antenna Unit
Example UNIT:POW DBUAM
Dependencies Grayed out if no Amplitude Correction with an Antenna Unit is on.
Readback dBµA
Initial S/W Revision A.11.00
dBpΤ
Sets the amplitude unit for the selected amplitude scale (log/lin) to dBpT. This is an antenna unit, and this
key is grayed out unless a Correction with this Antenna Unit selected is ON. If this is the case, all of the
other Antenna Units are grayed out.
Key Path
AMPTD Y Scale, Y Axis Unit, Antenna Unit
Example UNIT:POW DBPT
Dependencies Grayed out if no Amplitude Correction with an Antenna Unit is on.
Readback dBpT
Initial S/W Revision A.02.00
dBG
Sets the amplitude unit for the selected amplitude scale (log/lin) to dBG. This is an antenna unit, and this
key is grayed out unless a Correction with this Antenna Unit selected is ON. If this is the case, all of the
other Antenna Units are grayed out.
Key Path
AMPTD Y Scale, Y Axis Unit, Antenna Unit
Example UNIT:POW DBG
Dependencies Grayed out if no Amplitude Correction with an Antenna Unit is on.
Readback dBG
Initial S/W Revision A.02.00
EMI Receiver Mode Reference 739
