8 Frequency Scan Measurement
Recall
Default Directory
Specifies the default directory used for loading of Amplitude Correction. If user is selected, the default
recall directory is the default (My Documents\amplitudeCorrections) or the last directory you saved the
amplitude correction data to. Otherwise, the default recall directory is My Documents\EMC Limits and
Ampcor\Ampcor, which contains a set of preloaded amplitude correction files in the directory called
Ampcor.
Key Path
Recall, Export Data, Amplitude Correction
Remote Command
:MMEMory:LOAD:CORRection:DDIRectory USER|PRELoaded
Example :MMEM:LOAD:CORR:DDIR USER Select user
:MMEM:LOAD:CORR:DDIR?
Notes USER = User
PRELoaded = Preloaded
Preset PRELoaded
State Saved Saved in instrument state.
Range User| Preloaded
Readback “User”| “Preloaded”
Initial S/W Revision A.13.00
Trace
This key selects Trace as the data type to be imported. When pressed a second time, it brings up the Trace
Menu, which lets you select the Trace into which the data will be imported.
The trace file contains “meta” data which describes the state of the analyzer when the trace was exported
(see ). If the meta data in the file does not match the current SA state, the “invalid data indicator” (*) is
displayed.
Key Path
Recall, Data
Remote Command
:MMEMory:LOAD:TRACe:DATA TRACE1|TRACE2|TRACE3,<filename>
Example :MMEM:LOAD:TRAC DATA TRACE2, "myTrace2.csv" imports the 2nd trace from the file
myTrace2.csv in the current path. The default path is My Documents\EMI\data\xxx\traces where xxx
is the measurement name.
Dependencies A trace cannot be recalled from a trace file that was exported with ALL traces selected.
A trace cannot be imported if the number of trace points in the file do not match the number of
sweep points currently set for the measurement. If this happens, an error message is generated.
Errors are reported if the file is empty or missing, or if the file type does not match, or if there is a
mismatch between the file type and the destination data type.
If any error occurs while trying to load a file manually (as opposed to during remote operation), the
analyzer returns to the Import Data menu and the File Open dialog goes away.
Couplings When a trace is imported, Trace Update is always turned OFF for that trace and Trace Display is
always turned ON.
534 EMI Receiver Mode Reference
